Cisco WS-C3560G-24PS-S 24-Port Gigabit PoE Layer 3 Managed Switch | 4× SFP Uplink
The Cisco Catalyst WS-C3560G-24PS-S is an enterprise-class Layer 3 managed switch designed for reliable, scalable, and secure business network deployments. Built on the Cisco Catalyst 3560G Series platform, it delivers advanced switching performance, intelligent QoS, and basic Layer 3 routing capabilities using Cisco IOS IP Base software.
It comes with 24 × 10/100/1000 Mbps Gigabit PoE Ethernet ports and 4 × Gigabit SFP uplink ports, enabling flexible fiber connectivity for enterprise access and aggregation networks. With full IEEE 802.3af PoE support, the switch can power devices such as IP phones, wireless access points, and IP cameras directly through Ethernet ports with a total PoE budget of up to 370W.
The switch delivers a 32 Gbps switching matrix and 38.7 Mpps forwarding rate, ensuring stable and high-speed traffic handling for enterprise environments. It supports advanced Layer 3 features including static routing, RIP, EIGRP stub, PIM stub, and HSRP, with upgrade options to IP Services for full dynamic routing capabilities like OSPF and BGP.
With support for jumbo frames up to 9,018 bytes, configurable MTU up to 9,000 bytes, and a 12,000-entry MAC address table, the WS-C3560G-24PS-S is built for scalable enterprise networks. Its compact 1U rack-mount design makes it ideal for data centers, enterprise racks, offices, and institutional deployments.
Key Features
- 24 × Gigabit Ethernet PoE ports (10/100/1000 Mbps)
- 4 × Gigabit SFP uplink ports for fiber connectivity
- Enterprise Layer 3 managed switch (Cisco IOS IP Base)
- Full IEEE 802.3af PoE with 370W total power budget
- Supports IP phones, APs, and IP cameras via PoE
- 32 Gbps switching capacity with high-performance architecture
- 38.7 Mpps forwarding rate for fast packet processing
- Layer 3 features: Static routing, RIP, EIGRP stub, PIM stub, HSRP
- Upgradeable to IP Services for OSPF, BGP, and advanced routing
- Supports jumbo frames up to 9,018 bytes
- 12,000 MAC address table with scalable VLAN support
- 1U rack-mountable enterprise design
