Cisco WS-C3560X-24T-S 24-Port Gigabit Layer 3 Managed Switch | Modular Uplink Support | IP Base Enterprise Switch

Description

Cisco WS-C3560X-24T-S 24-Port Gigabit Layer 3 Managed Switch | Modular Uplink Support

The Cisco Catalyst WS-C3560X-24T-S is an enterprise-class Layer 3 standalone managed switch designed for high performance, scalability, and secure network operations. As part of the Cisco Catalyst 3560-X Series, it delivers advanced switching capabilities, energy efficiency, and flexible deployment options for enterprise and campus networks.

It features 24 × 10/100/1000 Gigabit Ethernet ports with no PoE support, making it ideal for data-only access layer deployments. The switch supports optional hot-swappable uplink network modules, allowing flexibility to choose between 1G and 10G fiber or copper uplinks based on network requirements.

With a powerful 160 Gbps switching fabric and up to 65.5 Mpps forwarding rate, the WS-C3560X-24T-S ensures smooth traffic handling for high-density enterprise environments. It also supports advanced Layer 3 features, VLAN scalability, and Jumbo frame support for optimized performance.

Its 1U rack-mount design, modular uplink flexibility, and enterprise-grade Cisco IOS IP Base software make it a reliable choice for business networks requiring stability and scalability.

Key Features

• 24 × Gigabit Ethernet (10/100/1000) RJ-45 ports
• Layer 3 standalone managed switch (Cisco Catalyst 3560-X Series)
• No PoE support (data-only switch)
• Optional hot-swappable uplink modules (1G / 10G SFP / 10G-T)
• 160 Gbps switching fabric for high-performance networking
• Up to 65.5 Mpps forwarding rate
• Advanced VLAN support and enterprise routing features (IP Base IOS)
• Jumbo frame support up to 9,216 bytes
• Energy-efficient and scalable enterprise design
• 1U rack-mount form factor for professional deployments
